Timex M108
Ligne: 12'''
Jewels: 25
Lift Angle: 55°
Power Reserve: 46 hrs
Frequency: 21600 vph
Type: Automatic
Period used: 1967-1968
Diameter: 27.4 mm
Height: 5.25 mm
Hands: 1.50 x 0.90 x 0.20 mm
The Timex M108 is a mechanical watch movement that was in use during the period of 1967-1968. It features a sophisticated excenter self-winding mechanism with just one gear stage and Diafix combined settings for the escapement wheel. This movement is equipped with several functions including automatic winding, sweep second hand, day display, quickset date adjustment by repeatedly pushing the crown, and a hack feature.
The Timex M108 features the following functions:
- Automatic Winding
- Calendar
- Date: quickset by repeated pushing the crown
- Day
- Hack feature
- No Manual Wind
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
