Fontainemelon 7013
(Font)
Ligne: 4.5 x 10'''
Jewels: 15/17
Power Reserve: 31 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Size: 10.1 x 22.6 mm
Height: 3.6 mm
Hands: 0.95 x 0.55 mm
The Fontainemelon 7013 watch movement is a manual wind movement that was commonly used around the period of 1940. Not much information is available regarding the differences between the ETA 746 and the Fontainemelon 7013 movements.
The Fontainemelon 7013 features the following functions:
- Manual Winding
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.40 x 0.070 x 245 x 7.0 mm | Manual | Buy mainspring | |
| 1.30 x 0.110 x 300 x 9.0 mm | GR3283 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
