Baumgartner 866
Ligne: 9.75'''
Jewels: 6/15
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1945
Diameter: 21.7 mm
Height: 4.0 mm
Hands: 1.20 x 0.60 mm
The Baumgartner 866 is a mechanical watch movement that was commonly used around the year 1945. It features manual winding and includes a sub-second function. Detailed differences between the Baumgartner 866 and other similar movements such as the 145, 168, 201, 204, and 229 are not known.
The Baumgartner 866 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.090 x 280 x 8.0 mm | GR4100 | Manual | Buy mainspring |
| 1.45 x 0.130 x 300 x 10.0 mm | GR40071 | Manual | Buy mainspring |
| 1.10 x 0.090 x 250 x 8.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
