Zenith 88.8-6
Ligne: 11.5'''
Jewels: 17
Lift Angle: 52°
Power Reserve: 48 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1980
Diameter: 26 mm
Height: 4.45 mm
Hands: 1.40 x 0.90 x 0.21 mm
The Zenith 88.8-6 is a mechanical watch movement designed with a unique arrangement where the train and hand gears are driven separately by the barrel. This design facilitates a low profile and accommodates a large balance wheel. However, it necessitates highly precise and shake-free gears due to the complex coupling between the second- and minute hand. The movement features manual winding and includes functions such as sweep seconds, quickset day, and quickset date. It was commonly used around the 1980s.
The Zenith 88.8-6 features the following functions:
- Date: quickset
- Day: quickset
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.110 x 320 x 10.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
