Zenith 1731
Ligne: 5.75 x 6.75'''
Jewels: 23
Lift Angle: 50°
Power Reserve: 43 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1966
Size: 13 x 15.2 mm
Height: 3.2 mm
Hands: 1.00 x 0.55 mm
The Zenith 1731 watch movement is a manual wind mechanical movement that was commonly used around the year 1966. This summary does not include any information about the differences between the 5AN and 5AR movements as that detail is not known.
The Zenith 1731 features the following functions:
- Manual Winding
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.070 x 200 x 6.0 mm | GR3185 | Manual | Buy mainspring |
| 1.30 x 0.070 x 180 x 6.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
Documents
Parts Listing
