Westclox 3
Ligne: 10.5'''
Jewels: 15/17
Lift Angle: 52°
Power Reserve: 40 hrs
Frequency: 18000 vph
Type: Manual Wind
Diameter: 23.7 mm
Height: 4.5 mm
Hands: 1.31 x 0.85 x 0.22 mm
The Westclox 3 is a manual wind watch movement that features sweep seconds. It shares similarities with the A. Schild 1497, but the differences between the two are not known.
The Westclox 3 features the following functions:
- Manual Winding
- Sweep Seconds
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 173 | Ordinary/None | Buy staff |
| 5451 | Ordinary/None | Buy staff |
| 280 | Incabloc | Buy staff |
| 5305 | Incabloc | Buy staff |
| 3256 | Supershock | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.100 x 300 x 9.0 mm | GR4122 | Manual | Buy mainspring |
| 1.50 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring | |
| 1.50 x 0.105 x 280 x 9.0 mm | GR41332 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
