Waltham 650
Ligne: 6.75 x 7.75'''
Jewels: 15
Power Reserve: 37 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1955
Size: 15.35 x 17.5 mm
Height: 3.4 mm
Hands: 0.95 x 0.50 mm
Base: Gruen 215
The Waltham 650 is a manual wind watch movement manufactured around 1955. It incorporates a Breguet hairspring and offers various functions that have not been elaborated upon.
The Waltham 650 features the following functions:
- Manual Winding
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.080 x 220 x 6.5 mm | GR2869 | Manual | Buy mainspring |
| 1.20 x 0.080 x 200 x 6.5 mm | GR2868 | Manual | Buy mainspring |
| 1.20 x 0.080 x 190 x 6.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
