Waltham 1904
Ligne: 10.5'''
Jewels: 15
Power Reserve: 36 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1936
Diameter: 23.7 mm
Height: 3.9 mm
Hands: 1.30 x 0.80 / 0.22 mm
The Waltham 1904 watch movement is part of a series of movements that were produced with various bridge layouts. It was likely also labeled as AS 341 in some cases, and its individual designations were listed in old data sheets. The differences between the 341, 346, 347, 349, 363, 384, 389, 436, 464, 514, 562, 583, 708, 932, and 934 variations are currently unknown. The Waltham 1904 movement is a manual wind movement featuring a sub seconds function. It was primarily used around 1936.
The Waltham 1904 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring | |
| 1.50 x 0.105 x 280 x 9.0 mm | GR41332 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
