Waltham 1899
Ligne: 8.75'''
Jewels: 15
Power Reserve: 36 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1938
Diameter: 19.7 mm
Height: 4.4 mm
Hands: 1.30 x 0.80 x 0.20 mm
Base: Felsa 163
The Waltham 1899 watch movement is a hybrid between the Felsa 163 and Felsa 359 models. This movement features a lever and escape wheel both made of gold. It is a manual wind movement with a sweep second function, and was commonly used around the year 1938.
The Waltham 1899 features the following functions:
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.40 x 0.080 x 250 x 7.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
