Valjoux 7730
Ligne: 11.5'''
Jewels: 17
Power Reserve: 42 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1960
Diameter: 25.9 mm
Height: 4.9 mm
Hands: 1.30 x 0.85 x 0.20 mm
Base: A. Schild 1686
The Valjoux 7730 watch movement is a manual wind movement that features a sweep second hand and incorporates Incabloc Shock Protection. This movement was commonly used in watches produced around the period of 1960. The specific differences between the Valjoux 7730 and the 1795 movement are not currently known.
The Valjoux 7730 features the following functions:
- Incabloc Shock Protection
- Manual Winding
- Sweep Seconds
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 5446 | Ordinary/None | Buy staff |
| 4847 | Incabloc | Buy staff |
| 5446 | Incabloc | Buy staff |
| 4847 | Kif | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.60 x 0.100 x 300 x 9.0 mm | GR4486 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
