Valjoux 320
Ligne: 10.5'''
Jewels: 17
Lift Angle: 51°
Power Reserve: 49 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1960-1966
Diameter: 23.3 mm
Height: 3.4 mm
Hands: 1.40 x 0.90 x 0.20 mm
The Valjoux 320 watch movement, used from 1960 to 1966, features a manual winding mechanism and a sweep seconds function. The movement is characterized by an early fixed or later mobile stud carrier, with no detailed distinctions observed between models 335-337 and 1005.
The Valjoux 320 features the following functions:
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
