Unitas 632
Ligne: 18'''
Jewels: 15/17
Power Reserve: 32 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1914-
Diameter: 39 mm
Height: 3.8 mm
Hands: 1.58 x 0.71 / 0.25 mm
The Unitas 632 is a mechanical watch movement that was in use from 1914 onwards. It is an open face calibre movement with a bimetallic screw balance. It offers the option of a Beguet hairspring or Reed's regulator. The movement features an early two-section regulator for coarse and fine adjustment. It has the functions of stem winding and setting, as well as a small sub-second dial.
The Unitas 632 features the following functions:
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.200 x 440 x 16.0 mm | GR4351T | T | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
