Unitas 515
Ligne: 19'''
Jewels: 15
Power Reserve: 38 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1950
Diameter: 41.8 mm
Height: 5.35 mm
Hands: 1.76 x 1.10 / 0.28 mm
The Unitas 515 watch movement is a hunter calibre with a Breguet hairspring. It features stem winding and setting, along with a sub-second function. The movement was most commonly used during the period around 1950.
The Unitas 515 features the following functions:
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.90 x 0.230 x 480 x 19.0 mm | GR5698 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
