Unitas 165
Ligne: 8.75'''
Jewels: 15
Power Reserve: 36 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1925
Diameter: 19.7 mm
Height: 3.3 mm
Hands: 1.10 x 0.60 mm
The Unitas 165 is a manual wind watch movement with a sub-second function. It features a bimetallic screw balance and was most commonly used around the year 1925.
The Unitas 165 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.080 x 240 x 7.0 mm | GR3202 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| MAINSPRING 1.30-.08-240 7 | MS-413E | GR 3202 | Buy part |
| PALLET ARBOR | 72S/84P | 714/AS 500 | Buy part |
| ROLLER 190X80X36 | 82S/58R | Buy part | |
| ROLLER, INCABLOC 190X80X36 | 82S/153R | Buy part | |
| STAFF | 100/38 | Buy part | |
| STEM | 200/12F | Buy part |
