Unitas 11
Ligne: 11.5'''
Jewels: 1/5/14/17
Lift Angle: 42°
Power Reserve: 39 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1975
Diameter: 26 mm
Height: 5.5 mm
Hands: 1.50 x 0.90 mm
The Unitas 11 watch movement is equipped with a pin-lever escapement and features an indirect minute hand friction clutch on the barrel. It is a manual wind movement and includes additional functions such as a date display and a sweep seconds hand. The Unitas 11 movement was commonly used around 1975.
The Unitas 11 features the following functions:
- Date
- Manual Winding
- Sweep Seconds
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.15 x 0.120 x 320 x 10.5 mm | Manual | Buy mainspring | |
| 1.15 x 0.110 x 320 x 9.5 mm | GR28051 | Manual | Buy mainspring |
| 1.10 x 0.100 x 320 x 9.0 mm | GR2615 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
