Tissot 709-1
Jewels: 19
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1897-1913
Diameter: 39.75 mm
Height: 5.0 mm
Hands: 1.50 x 0.92 / 0.26 mm
The Tissot 709-1 watch movement, produced from 1897 to 1913 with a total of 10,000 units, features an open face calibre known as model 3. This movement incorporates a bimetallic screw balance, Breguet hairspring, and a pink-gold center wheel. It also includes a negative stem mechanism with an additional lever, enabling the user to switch between winding and setting functions using the crown in the lever position. Additionally, this movement includes a sub-second function.
The Tissot 709-1 features the following functions:
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.05 x 0.200 x 520 x 15.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
