Smith 27.CS
Ligne: 12'''
Jewels: 0/1
Power Reserve: 37 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1965
Diameter: 28.05 mm
Height: 4.7 mm
Hands: 1.95 x 1.10 mm
The Smith 27.CS watch movement from circa 1965 features a pin-lever escapement, an indirect minute hand friction clutch on the barrel, and a flying barrel. It is notable for its ingenious design where one simple part replaces the setting-lever spring, yoke, and yoke spring. The movement offers manual winding, sub-second function, and a date display.
The Smith 27.CS features the following functions:
- Date
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.110 x 630 x 14.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
