Seiko 5619A
Ligne: 11.5'''
Jewels: 17/21
Power Reserve: 41 hrs
Frequency: 21600 vph
Type: Automatic
Period used: 1961-
Diameter: 26 mm
Height: 5.1 mm
Hands: 1.50 x 0.90 x 0.21 mm
The Seiko 5619A watch movement is an automatic mechanism based on the manual wind calibre AS 1687/1688. It was co-developed by Doxa, Eberhard, Favre-Leuba, Girard-Perregaux, and Zodiac. The movement features a sweep second hand, and includes an automatic function and calendar. Additionally, the date can be set by changing the 21-24h. The Seiko 5619A watch movement has been in use since 1961.
The Seiko 5619A features the following functions:
- Automatic Winding
- Calendar
- Date: set by changing 21-24h
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 5207 | Ordinary/None | Buy staff |
| 5207 | Incabloc | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.110 x 320 x 10.0 mm | GR3699X | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
