Ronda 115P
Ligne: 10.5'''
Jewels: 15/17
Power Reserve: 45 hrs
Frequency: 18000 vph
Type: Manual Wind
Diameter: 23.7 mm
Height: 3.5 mm
Hands: 1.30 x 0.70 / 0.22 mm
The Ronda 115P is a manual wind watch movement that features a sub-second hand and calendar function. While there might be minor differences between the 1317 and other A. Schild movements such as the 1200, 1247, and 1288, these variations are not explicitly known.
The Ronda 115P features the following functions:
- Calendar
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.60 x 0.100 x 300 x 9.0 mm | GR4486 | Manual | Buy mainspring |
| 1.60 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
