Revue GT14
Ligne: 17'''
Jewels: 15
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1930
Diameter: 38.7 mm
Height: 5.05 mm
Hands: 1.75 x 1.10 / 0.22 mm
Base: Cyma Tavannes 774
The Revue GT14 watch movement is an open face calibre with a Breguet hairspring. While the specific jewel count differences between the 737 and 777 models are not known, the two movements may share similar features. The movement offers functions such as stem wind and set, sub seconds, left setting, stem winding, and was commonly used around the 1930s.
The Revue GT14 features the following functions:
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.80 x 0.175 x 500 x 15.0 mm | GR5380 | Manual | Buy mainspring |
| 1.80 x 0.180 x 450 x 15.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| PALLET ARBOR | 72S/122P | 714/TAV 764 | Buy part |
| SCREW, CLUTCH LEVER | 5445/221 | Buy part | |
| SET BRIDGE | 445/998 | 21/3 | Buy part |
| SET SPRING FLAT | 440/806 | 19/2 | Buy part |
| STAFF= TAV 764 .75 HSPG. | 100/2 | Buy part | |
| STEM | 200/948F | Buy part |
