Revue 356
Ligne: 13'''
Jewels: 1
Lift Angle: 42°
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1980
Diameter: 29.33 mm
Hands: 2.00 x 1.20 mm
The Revue 356 manual wind watch movement features a pin-lever escapement and an indirect minute, hand friction clutch on the barrel. It also includes a sub-second function. The movement was commonly used around the approximate period of 1980.
The Revue 356 features the following functions:
- Manual Winding
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.125 x 14.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
