Recta C
Ligne: 8.75'''
Jewels: 7/15/17
Lift Angle: 52°
Power Reserve: 45 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1935-1967
Diameter: 19.4 mm
Height: 3.45 mm
Hands: 1.20 x 0.65 / 0.18 mm
The Recta C watch movement is a manual wind movement that features a sub second function. Produced between 1935 and 1967, over 16,000,000 units were manufactured without a separate escape-wheel cock. The movements within this family were constructed with different balances and had varying calibre designations; however, these differences were minor enough to allow for interchangeable parts. Additionally, there are other calibres with a similar appearance and a movement height of 3.0mm.
The Recta C features the following functions:
- Manual Winding
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 143 | Ordinary/None | Buy staff |
| 262 | Ordinary/None | Buy staff |
| 2851 | Ordinary/None | Buy staff |
| 292 | Ordinary/None | Buy staff |
| 3245 | Ordinary/None | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.60 x 0.080 x 250 x 7.5 mm | Manual | Buy mainspring | |
| 1.60 x 0.080 x 260 x 7.0 mm | GR4446 | Manual | Buy mainspring |
| 1.60 x 0.080 x 240 x 7.0 mm | GR4445 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
Documents
Parts Listing
