Raketa 2609.H
Ligne: 13'''
Jewels: 17
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Diameter: 29.33 mm
The Raketa 2609.H is a manual-wind chronograph movement with functions including a 60-second and 30-minute chronograph, controlled by a pillar wheel mechanism. It also features a sub second dial. This movement was commonly used in watches produced in the approximate period of 1940.
The Raketa 2609.H features the following functions:
- Chronograph Movement
- Manual-wind chronograph, 60s, 30min, pillar wheel
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.60 x 0.140 x 340 x 11.0 mm | GR4588 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
