Raketa 2603
Ligne: 15'''
Jewels: 15
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Diameter: 33.85 mm
Height: 4.6 mm
Hands: 1.60 x 1.00 / 0.18 mm
The Raketa 2603 is a mechanical watch movement of the open face calibre family. There are no known differences between the 575 and 577 movements. The movement features stem winding and setting, as well as a sub-second function. It was typically used in watches produced around the year 1940. Further details and specifications about the movement are not provided.
The Raketa 2603 features the following functions:
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.65 x 0.160 x 360 x 13.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
