Peseux 40
Ligne: 12.25'''
Jewels: 17
Power Reserve: 45 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1968
Diameter: 28.1 mm
Height: 4.45 mm
Hands: 1.50 x 0.90 x 0.20 mm
Base: Seiko 66B
The Peseux 40 is a manual-wind mechanical watch movement with a sweep seconds function and a date feature that can be set by changing the time between 21:30 and 24h. It utilizes a stem mechanism without a setting-lever spring and incorporates Diafix combined settings for the escapement wheel. This movement was commonly used in watches produced around 1968.
The Peseux 40 features the following functions:
- Date: set by changing 21:30-24h
- Manual Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.35 x 0.110 x 380 x 9.0 mm | GR3510 | Manual | Buy mainspring |
| 1.30 x 0.115 x 340 x 10.0 mm | GR3296 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
