Patek Philippe 18
Ligne: 10.5'''
Jewels: 17/21
Lift Angle: 52°
Power Reserve: 47 hrs
Frequency: 18000 vph
Type: Manual Wind
Diameter: 23.7 mm
Height: 3.6 mm
Hands: 1.50 x 0.90 x 0.21 mm
The Patek Philippe 18 watch movement is characterized by its early fixed or later mobile stud carrier. The differences between the 2390, 2392, 2394, 2396, 2398, 2400, 2402, and 2404 versions are not known. The movement features manual wind, sweep second, offset center wheel, sweep seconds, hours, minutes, and central seconds functions.
The Patek Philippe 18 features the following functions:
- Central seconds
- Hours
- Manual Winding
- Minutes
- Offset Center Wheel
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 4377 | Ordinary/None | Buy staff |
| 4040 | Ordinary/None | Buy staff |
| 4935 | Ordinary/None | Buy staff |
| 4049 | Incabloc | Buy staff |
| 3946 | Incabloc | Buy staff |
| 5136 | Incabloc | Buy staff |
| 5436 | Incabloc | Buy staff |
| 4801 | Supershock | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.110 x 340 x 10.0 mm | GR3285 | Manual | Buy mainspring |
| 1.30 x 0.110 x 320 x 10.0 mm | Manual | Buy mainspring | |
| 1.30 x 0.110 x 320 x 9.5 mm | GR3284 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More | |||
| See More | |||
| See More | |||
| See More | |||
| See More | |||
| See More |
Documents
Parts Listing
