Otero 797K
Ligne: 11.5'''
Jewels: 17/21
Power Reserve: 41 hrs
Frequency: 21600 vph
Type: Automatic
Period used: 1961-
Diameter: 26 mm
Height: 4.8 mm
Hands: 1.50 x 0.90 x 0.21 mm
The Otero 797K watch movement is an automatic mechanism that was developed jointly by Doxa, Eberhard, Favre-Leuba, Girard-Perregaux, and Zodiac. It is based on the manual wind calibre AS 1687/1688 and features a regulation gear. The movement incorporates various functions, including sweep seconds, offset center wheel, automatic winding system, and Incabloc shock protection. The Otero 797K movement was used from 1961 onwards.
The Otero 797K features the following functions:
- Automatic Winding
- Incabloc Shock Protection
- Offset Center Wheel
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 5207 | Ordinary/None | Buy staff |
| 5207 | Incabloc | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.110 x 320 x 10.0 mm | GR3699X | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
