Mido 707PC
Ligne: 13.5'''
Jewels: 17/31
Lift Angle: 52°
Power Reserve: 50 hrs
Frequency: 36000 vph
Type: Automatic
Period used: 1969-
Diameter: 30 mm
Height: 6.5 mm
Hands: 1.50 x 1.00 x 0.20 / 0.20 x 0.20 x 0.22 mm
The Mido 707PC watch movement is an automatic chronograph movement with a pillar wheel mechanism. It includes functions such as a sub second, quickset date, 60s, and 30min chronograph. The movement also features an automatic winding system with a ball-bearing rotor. This movement has been used since 1969.
The Mido 707PC features the following functions:
- Automatic chronograph, 60s, 30min, 12h, pillar wheel
- Automatic Winding
- Ball-bearing Rotor
- Calendar
- Chronograph Movement
- Date: quickset
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.22 x 0.146 x 12.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
