Lemania 8815
Ligne: 11.5'''
Jewels: 17
Frequency: 21600 vph
Type: Automatic
Period used: ~1980
Diameter: 26 mm
Height: 5.0 mm
Hands: 1.40 x 0.90 x 0.22 mm
The Lemania 8815 watch movement, designed around the 1980s, incorporates a unique feature where the train and hand gear are individually driven by the barrel. This design enables a low profile and provides ample space for a large balance. However, it necessitates precision manufacturing and sturdy gears due to the intricate coupling between the second and minute hands. Additionally, this movement offers functions such as an automatic winding system and a sweep second hand.
The Lemania 8815 features the following functions:
- Automatic Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.120 x 325 x 10.0 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
