Lemania 1277
Ligne: 11.5'''
Jewels: 17/21
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1956-
Diameter: 26 mm
Height: 3.95 mm
Hands: 1.30 x 0.80 x 0.22 mm
The Lemania 1277 watch movement is a manual wind mechanical movement with a sweep second function. It features a date indicator that can be set by changing the time from 20:30 to 24h. This movement has been in use since 1956.
The Lemania 1277 features the following functions:
- Date: set by changing 20:30-24h
- Manual Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.100 x 340 x 9.5 mm | GR2922 | Manual | Buy mainspring |
| 1.20 x 0.120 x 270 x 9.5 mm | Manual | Buy mainspring | |
| 1.20 x 0.120 x 280 x 9.0 mm | GR2971 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| 3361 | 2576/DUR 585 | Buy part | |
| 72S S/C | 254P | /DUR 570/1 | Buy part |
| BALANCE COMPLETE | 710/1153 | 2910 | Buy part |
| BALANCE COMPLETE | 721/1081 | /DUR 590/1 | Buy part |
| CLUTCH WHEEL | 407/991 | 3144 | Buy part |
| DATE DRIVE WHEEL | A/2985 | 2556/DUR 1285 | Buy part |
| MAINSPRING 1.20-.10-340 9,5 | MS-311P | GR 2922 | Buy part |
| PALLET ARBOR | 72S/76P | 714/DUR 450 | Buy part |
| RATCHET WHEEL | 415/132 | Buy part | |
| ROLLER 190X90X36 | 82S/60R | Buy part | |
| SCREW, DATE IND GUARD | A/3375 | 52535/DUR 1285 | Buy part |
| SCREW, ROTOR WEIGHT | A/3577 | 3176/ROL | Buy part |
| STAFF, REG/DUROSWING | 100/1838 | Buy part | |
| STEM | 200/1362F | 401/DUR 451 | Buy part |
| T8 | 1249F | /DUR 585 | Buy part |
| WINDING PINION | 410/1026 | Buy part | |
| WINDING PINION | 410/1260 | Buy part |
