The Kienzle 57/22 watch movement, produced exclusively for Mido from 1954 to 1960, features a base plate derived from the AS 1131/1132 movement. Some later samples of the movement include a larger date function. Optional black rhodium plating is available for this movement. The Kienzle 57/22 can be equipped with the optional Fonto regulator, which has a mobile stud carrier and an adjustable regulator pin-width. Another optional regulator for this movement is the Incastar regulator, which is unique in its use of a free oscillating hairspring fixed between two rollers to adjust its length, ensuring no isochronism error caused by the gap between the regulator pins. The Kienzle 57/22 offers automatic winding and sweep seconds, as well as a date function.
The Kienzle 57/22 features the following functions:
| Ronda Reference # | Shock System | Buy |
|---|
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.35 x 0.090 x 280 x 8.5 mm | GR3498X | Auto | Buy mainspring |
| 1.35 x 0.090 x 250 x 8.0 mm | Auto | Buy mainspring |
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
