Kienzle 57/22
Ligne: 13'''
Jewels: 27
Power Reserve: 47 hrs
Frequency: 18000 vph
Type: Automatic
Period used: 1962-
Diameter: 29.4 mm
Height: 5.3 mm
Hands: 1.52 x 1.00 x 0.18 mm
The Kienzle 57/22 watch movement, introduced in 1962, features an automatic mechanism with a ring rotor that rotates on 9 balls. Additionally, this movement includes functions such as a sweep second hand and a date display that can be quickly set by repeatedly pulling the crown.
The Kienzle 57/22 features the following functions:
- Automatic Winding
- Date: quickset by repeated pulling the crown
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
