Kienzle 146/31
Ligne: 5.75 x 8.5'''
Jewels: 15/17
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1955
Size: 12.9 x 19.5 mm
Hands: 1.00 x 0.50 mm
The Kienzle 146/31 watch movement, which shares similarities with the 510, 512, 515, 520 through 524, and 533 movements, is a manual wind movement. It was commonly employed in watches produced around the year 1955. Further distinctions and functionalities of this movement are not known.
The Kienzle 146/31 features the following functions:
- Manual Winding
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.080 x 260 x 7.5 mm | GR40771 | Manual | Buy mainspring |
| 1.50 x 0.080 x 245 x 7.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| GIB/BOLT INCA 240X19 THICK | 400/1 | 180.19/INCA #11 | Buy part |
| JEWEL, INCA BALANCE 135X50X09 | 400/11 | 111.09/INCA#8 | Buy part |
| JEWEL, INCA UPPER CAP 120X27 | 400/7 | 121.11/INCA #5 | Buy part |
| JEWEL, UPPER CAP INCA 120X18 | 400/8 | 122.11/INCA #6 | Buy part |
| LOWER INCA SETTING D160 H9 | 400/38 | 112.20.9 | Buy part |
| SCREW, INCA SHOCK .15X.50 | 400/809 | 150.21/INCA #14 | Buy part |
| SHOCK SPRING, LOWER INCABLOC | 400/6 | 172.03/INCA #4 | Buy part |
| SHOCK SPRING, UPPER INCABLOC | 400/4 | 170.03/INCA #1 | Buy part |
| UPPER UNIT D295 H9 | 100.11.295.9 | Buy part |
