Kienzle 060A22
Ligne: 18'''
Jewels: 15
Power Reserve: 38 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Diameter: 41.7 mm
Height: 4.8 mm
Hands: 1.75 x 1.05 / 0.25 mm
The Kienzle 060A22 watch movement is an open face calibre with a monometallic screw balance and a Breguet hairspring. It features different bridge shapes. The movement offers functions such as stem winding and setting, as well as a sub-second display. This model was typically used in timepieces manufactured around 1940.
The Kienzle 060A22 features the following functions:
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.80 x 0.200 x 460 x 16.0 mm | GR5415 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
