Kienzle 058C11
Ligne: 18.5'''
Jewels: 15
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1925
Diameter: 41.8 mm
Height: 4.75 mm
Hands: 2.00 x 1.20 / 0.30 mm
The Kienzle 058C11 is an open face calibre movement with a recorded height range of 5.0 to 5.05mm. The movement is distinguished from the Felsa 247 and Felsa 249, although the exact differences are not specified. It features stem winding and setting, as well as a sub-second function. The Kienzle 058C11 movement was predominantly used around the year 1925.
The Kienzle 058C11 features the following functions:
- Stem wind and set
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.00 x 0.180 x 500 x 15.0 mm | GR5861 | Manual | Buy mainspring |
| 2.00 x 0.190 x 430 x 15.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
