Juvenia 11511
Ligne: 13.5'''
Jewels: 32
Power Reserve: 50 hrs
Frequency: 36000 vph
Type: Automatic
Period used: 2005-
Diameter: 30 mm
Height: 9.35 mm
Hands: 1.50 x 1.00 x 0.20 / 0.20 x 0.20 mm
The Juvenia 11511 is an automatic chronograph rattrapante watch movement introduced in 2005. It features a pillar wheel mechanism for precise control of the chronograph functions. The movement includes a split second function, which is activated by a pusher in the crown. Additionally, it has a sub-second display and a big date complication at the 6 o'clock position, which allows for quick setting.
The Juvenia 11511 features the following functions:
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.22 x 0.146 x 12.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
