Watch Database
Junghans J47D
Ligne: 11.5'''
Jewels: 17/21
Power Reserve: 48 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1960
Diameter: 26 mm
Height: 3.25 mm
Hands: 1.50 x 0.90 x 0.21 mm
The Junghans J47D watch movement is a manual wind movement with a sweep second function. It includes a date feature that can be set by changing the time between 20:40 and 24h. The movement is equipped with Incabloc Shock Protection and has a sweep seconds hand. It was commonly used around the period of 1960. There are no known differences between the Junghans J47D and Enicar 1171 movements.
The Junghans J47D features the following functions:
- Date: set by changing 20:40-24h
- Incabloc Shock Protection
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.120 x 320 x 9.5 mm | GR2973 | Manual | Buy mainspring |
| 1.20 x 0.130 x 300 x 9.5 mm | GR2988 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
