Junghans J47C/1
Ligne: 11.5'''
Jewels: 16/17/21
Power Reserve: 43 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1965
Diameter: 26 mm
Height: 3.1 mm
Hands: 1.30 x 0.80 / 0.21 mm
The Junghans J47C/1 is a mechanical watch movement that features a manual wind function and a sub second display. It is characterized by an early fixed or later mobile stud carrier. The specific differences between the Peseux 330 through 333, 337, and 338 movements are not known. The Junghans J47C/1 movement was commonly used around 1965.
The Junghans J47C/1 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.120 x 290 x 10.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
