Junghans 628.01
Ligne: 8.75'''
Jewels: 15/17
Power Reserve: 44 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1945
Diameter: 19.75 mm
Height: 3.5 mm
Hands: 1.20 x 0.60 / 0.20 mm
The Junghans 628.01 is a manual wind mechanical watch movement with a sub-second function. It is part of a range of movements (790-799, 802, 803, 807-809, 878, 881, 884) that share certain technical similarities or differences, which are not known in detail. The Junghans 628.01 movement was commonly used in watches during the period around 1945.
The Junghans 628.01 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.090 x 240 x 7.5 mm | GR4098 | Manual | Buy mainspring |
| 1.50 x 0.090 x 220 x 7.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
