Junghans 620.02
Ligne: 9.75'''
Jewels: 6/15
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1945
Diameter: 21.7 mm
Height: 3.4 mm
Hands: 1.20 x 0.60 mm
The Junghans 620.02 watch movement is a manual wind, sub second movement that was used around 1945. It shares the same designation as an earlier 5.25''' calibre movement, and there are no known differences between the Junghans 620.02, Felsa 186, and Felsa 245 movements.
The Junghans 620.02 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.70 x 0.090 x 240 x 7.5 mm | GR4851 | Manual | Buy mainspring |
| 1.10 x 0.090 x 250 x 8.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
