Jaeger Lecoultre 810
(JLC, Lecoultre)
Ligne: 10.5'''
Jewels: 17/21
Power Reserve: 44 hrs
Frequency: 21600 vph
Type: Manual Wind
Period used: ~1960
Diameter: 23.7 mm
Height: 2.8 mm
Hands: 1.30 x 0.70 / 0.22 mm
Base: Girard Perregaux 26.19
The Jaeger Lecoultre 810 is a manual wind watch movement with a sub-second function. It features a bridge layout that differs from the common AS 1758 design. This movement was utilized in watches manufactured around 1960.
The Jaeger Lecoultre 810 features the following functions:
- Manual Winding
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.100 x 300 x 9.0 mm | GR3254 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More | |||
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
