Jaeger Lecoultre 479
(JLC, Lecoultre)
Ligne: 11.5'''
Jewels: 1
Power Reserve: 38 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1975
Diameter: 26 mm
Height: 4.8 mm
Hands: 1.80 x 1.30 x 0.20 mm
The Jaeger Lecoultre 479 watch movement features a pin-lever escapement and a unique design where the train and hand gears are driven separately by the barrel. It is a manual wind movement that includes a sweep second hand. The movement is equipped with a day function that can be set by +/-24 hours and a date function that can be quickly adjusted through reverse setting. The Jaeger Lecoultre 479 movement was predominantly used during the period roughly around 1975.
The Jaeger Lecoultre 479 features the following functions:
- Date: quickset by reverse setting
- Day: set by +/-24h
- Manual Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.40 x 0.105 x 300 x 9.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
