Jaeger Lecoultre 438/4CAM
(JLC, Lecoultre)
Ligne: 5.25 x 6.75'''
Jewels: 17
Power Reserve: 35 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1950
Size: 12 x 15.2 mm
Height: 3.35 mm
Hands: 1.05 x 0.55 mm
The Jaeger Lecoultre 438/4CAM watch movement is a manual wind movement that was commonly used in watches around the 1950s period.
The Jaeger Lecoultre 438/4CAM features the following functions:
- Manual Winding
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.10 x 0.080 x 200 x 6.5 mm | GR2577 | Manual | Buy mainspring |
| 1.10 x 0.070 x 185 x 6.0 mm | Manual | Buy mainspring | |
| 1.10 x 0.065 x 180 x 5.5 mm | GR2555 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
