Jaeger Lecoultre 30
(JLC, Lecoultre)
Ligne: 16'''
Jewels: 19
Power Reserve: 36 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1952-1959
Diameter: 36.5 mm
Height: 6.8 mm
Hands: 1.88 x 1.20 x 0.26 / 0.26 x 0.24 mm
The Jaeger Lecoultre 30 is a period-specific open face calibre watch movement, which was used from 1952 to 1959. The movement features a stem-wind chronograph function with a duration of 60 seconds and a sub-second function. It also includes a 30-minute chronograph and operates with a pillar wheel mechanism. Additionally, it offers the option of using a Breguet hairspring.
The Jaeger Lecoultre 30 features the following functions:
- Stem-wind chronograph with 60-second and 30-minute functions, featuring a pillar wheel
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
