Jaeger Lecoultre 11LO
(JLC, Lecoultre)
Ligne: 10.5'''
Jewels: 15
Power Reserve: 50 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1945
Diameter: 23.3 mm
Height: 3.55 mm
Hands: 1.30 x 0.60 / 0.21 mm
The Jaeger Lecoultre 11LO is a manual wind mechanical watch movement that features a sub-second function. It belongs to a series of movements numbered from 290 to 309, with specific differences not known. The Jaeger Lecoultre 11LO movement was used in watches produced around 1945.
The Jaeger Lecoultre 11LO features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.100 x 300 x 9.0 mm | GR4122 | Manual | Buy mainspring |
| 1.50 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
