Illinois GRD 60-S

Ligne: 14'''

Jewels: 19

Frequency: 18000 vph

Type: Manual Wind

Period used: ~1950

Diameter: 31.58 mm

Mainspring Listing

Dimensions	GR Reference #	End Type	Buy
1.45 x 0.130 x 420 x 11.0 mm	GR4014X	Auto	BuyBuy mainspring

Parts Listing

Part Description	Reference #	Alternate	Buy
AUTOMATIC DEVICE BRIDGE, UPPER	A/3627	1142/AS 1700	BuyBuy part
BALANCE COMPLETE	721/741		BuyBuy part
BALANCE COMPLETE	721/838	721/AS 1580 INC	BuyBuy part
BALANCE COMPLETE SCREWLESS INC	721/1700	*SHOCK/AS 1580	BuyBuy part
BARREL	182/652		BuyBuy part
BARREL ARBOR	195/664	195/AS 1580	BuyBuy part
BARREL BRIDGE	M/1179	105/AS 1580	BuyBuy part
BRIDLE	A/2388	755/AS 1580	BuyBuy part
BUSHING, AUTOMATIC DEVICE	A/452	1650/ETA 1216	BuyBuy part
BUSHING, U/L WIND WHL, DR GEAR	A/232	1675/AS 1336	BuyBuy part
CANNON PINION, SS HT 1.52	245/481	245/AS 1538	BuyBuy part
CANNON PINION, SS HT 1.77	245/601	245/AS 1538	BuyBuy part
CANNON PINION, SS HT 2.02	245/479	245/AS 1538	BuyBuy part
CANNON PINION, SS HT 2.27	245/484	245/AS 1538	BuyBuy part
CANNON PINION, SS HT 2.77	245/662	245/AS 1538	BuyBuy part
CANNON PINION, SS HT 3.02	245/1046	245/AS 1580	BuyBuy part
CASE CLAMP	A/633	166/FEL 690	BuyBuy part
CENTER COCK	M/1899	126/AS 1580	BuyBuy part
CENTER WHEEL, SS	206/343	206/AS 1580	BuyBuy part
CLICK	425/537 (use 425/442)	425/537	BuyBuy part
CLICKSPRING	430/541	430/AS 1700	BuyBuy part
CLUTCH LEVER	435/415	435/AS 1700	BuyBuy part
CLUTCH LEVER SPRING	440/544	440/AS 1700	BuyBuy part
CLUTCH WHEEL	407/610	407/AS 1580	BuyBuy part
CROWN WHEEL	420/706	420/AS 1700	BuyBuy part
CROWN WHEEL CENTER	422/313	422/STA 1686	BuyBuy part
DATE DIAL, YELLOW @3	A/3618	2557/1/AS 1681	BuyBuy part
DATE GUARD	A/3616	2535/AS 1681	BuyBuy part
DATE JUMPER	A/3621	2576/AS 1681	BuyBuy part
DATE JUMPER SPRING	A/3620	2575/AS 1681	BuyBuy part
DRIVING GEAR	A/2394	1482/AS 1581	BuyBuy part
ESCAPE WHEEL S/C	703/179		BuyBuy part
ESCAPE WHEEL, C/C	702/351		BuyBuy part
ESCAPE WHEEL, S/S	705/899	AS 1680	BuyBuy part
FOURTH WHEEL, SS HT 4.84	227/252		BuyBuy part
FOURTH WHEEL, SS HT 5.09	227/94		BuyBuy part
FOURTH WHEEL, SS HT 5.34	227/96		BuyBuy part
FOURTH WHEEL, SS HT 5.59	227/293	/AS 1700	BuyBuy part
FOURTH WHEEL, SS HT 5.84	227/294		BuyBuy part
FOURTH WHEEL, SS HT 6.09	227/295		BuyBuy part
GIB/BOLT INCA SHOCK .15 THICK	400/774	180.15/INCA #12	BuyBuy part
HOUR WHEEL, DOUBLE HT 1	A/3619	2558/AS 1701	BuyBuy part
HOUR WHEEL, SS HT 1.35	255/464	255/AS 1700	BuyBuy part
HOUR WHEEL, SS HT 1.60	255/584	255/AS 1700	BuyBuy part
HOUR WHEEL, SS HT 2.00	255/581		BuyBuy part
INTERMEDIATE DATE WHEEL	A/3617	2543/AS 1681	BuyBuy part
JEWEL, INCA BALANCE 135X50X10	400/12	111.10/INCA #9	BuyBuy part
JEWEL, LOWER BALANCE CAP	336/41		BuyBuy part
JEWEL, LOWER BALANCE CAP	330/224		BuyBuy part
JEWEL, LOWER ESCAPE CAP	346/34		BuyBuy part
JEWEL, LOWER PAL CAR	M/1374	348/AS 1635	BuyBuy part
JEWEL, UPPER BALANCE CAP	311/231	311/231	BuyBuy part
JEWEL, UPPER BARREL ARBOR	M/2564	636/AS 1700	BuyBuy part
JEWEL, UPPER CAP INCA 120X18	400/8	122.11/INCA #6	BuyBuy part
LOWER AUTOMATIC DEVICE BRIDGE	A/2389	1141/AS 1580	BuyBuy part
LOWER RATCHET WHEEL	A/2392	1416/AS 1581	BuyBuy part
MAINSPRING 1.20-.105-340 10	MSS-WA32	GR 2937-X	BuyBuy part
MINUTE COCK	462/38		BuyBuy part
MINUTE WHEEL	260/604	/AS 1806	BuyBuy part
OSCILLATING WEIGHT	A/3628	1143/1/AS 1700	BuyBuy part
OSCILLATING WEIGHT AXLE	A/2396	1496/AS 1580	BuyBuy part
OSCILLATING WEIGHT AXLE	A/3629	1496/AS 1700	BuyBuy part
OSCILLATING WEIGHT BOLT	A/3030	1491/AS 1580	BuyBuy part
OSCILLATING WEIGHT BOLT PLATE	A/3032	1527/AS 1580	BuyBuy part
PALLET ARBOR	714/44		BuyBuy part
PALLET ARBOR, S/S 40-100-10	72S/87P	714/AS 1007	BuyBuy part
PALLET FORK & ARBOR	710/692		BuyBuy part
PALLET FORK & ARBOR	710/1071	710/1071	BuyBuy part
PAWL WINDING WHEEL	A/2395	A/2395	BuyBuy part
PAWL WINDING WHEEL, W/JEWELS	A/1724	1488/5/AS 1580	BuyBuy part
RATCHET WHEEL	415/724	415/AS 1700	BuyBuy part
REDUCTION GEAR	A/2393	1481/AS 1581	BuyBuy part
REGULATOR	301/660		BuyBuy part
REGULATOR W/STUD HOLDER	301/969	307/AS 1580	BuyBuy part
ROLLER 180X75X36	82S/40R	730/31	BuyBuy part
ROLLER, GENUINE	730/31	/PES 336N	BuyBuy part
ROLLER, INCABLOC 180X75X36	82S/147R	730/AS 1649	BuyBuy part
SCREW, 2 ARM SPRING	M/1416	51121/AS 1700	BuyBuy part
SCREW, BALANCE BDG,PLATE LONG	5110/373	5121/AS 1045	BuyBuy part
SCREW, BEARING PLATE	5342/16	5342/AS 1530	BuyBuy part
SCREW, CASE	A/2397	5102/AS 1580	BuyBuy part
SCREW, CASE	5101/320		BuyBuy part
SCREW, CASE (FLAT HEAD)	5415/347	*5101/AS 1191	BuyBuy part
SCREW, CLICK	5425/264		BuyBuy part
SCREW, CROWN WHEEL	5420/401	5420/AS 1700	BuyBuy part
SCREW, DIAL SIDE	5750/303	11 0RACD BEV CUT	BuyBuy part
SCREW, DRIVING GEAR	A/2401	51482/AS 1580	BuyBuy part
SCREW, INCA SHOCK 18X60	400/3	160.11/INCA #15	BuyBuy part
SCREW, INT DATE WHEEL	A/3625	52543/AS 1681	BuyBuy part
SCREW, LOWER BAL CAP JEWEL	5330/63	5420/AS 1002	BuyBuy part
SCREW, MINUTE COCK	5462/218	5462/AS 1700	BuyBuy part
SCREW, MINUTE WHEEL COCK	5445/218	5462/AS 1580	BuyBuy part
SCREW, OSCILLATING WEIGHT AXLE	A/2402	51496/AS 1580	BuyBuy part
SCREW, PALLET BRIDGE	5125/170	5125/AS 1700	BuyBuy part
SCREW, RATCHET WHEEL	5415/339	5415/AS 1649	BuyBuy part
SCREW, SET LEVER	5443/773		BuyBuy part
SCREW, STUD	5738/198		BuyBuy part
SCREW, UNLOCKING YOKE	A/3626	52632/AS 1681	BuyBuy part
SCREW, UNLOCKING YOKE SPRING	A/3624	52633/AS 1681	BuyBuy part
SCREW, UPPER AUTO DEVICE-LONG	A/2400	51142/AS 1580	BuyBuy part
SCREW, UPPER AUTO DEVICE-SHORT	A/2398	51142/1-AS 1580	BuyBuy part
SCREW, UPPER BALANCE CAP JEWEL	5311/77		BuyBuy part
SET BRIDGE	445/676	445/676	BuyBuy part
SET LEVER	443/760	443/AS 1580	BuyBuy part
SET WHEEL	450/600	450/AS 1700	BuyBuy part
SHOCK SPRING, UPPER INCABLOC	400/4	170.03/INCA #1	BuyBuy part
SHOCK UNIT COMPLETE, LOWER	400/33	100.20.10	BuyBuy part
STAFF	100/1615		BuyBuy part
STAFF	723/606		BuyBuy part
STAFF, HSP 60 INCA	100/1802		BuyBuy part
STAFF, INCA HSP 30	100/2341		BuyBuy part
STAFF, INCA HSP 50	100/2185		BuyBuy part
STAFF, INCA RIV 22	100/2561		BuyBuy part
STAFF, INCA RIVET 3ARM	723/1128		BuyBuy part
STAFF, INCA RIVET W/SCREW	723/607		BuyBuy part
STAFF, RIV .22	100/2560		BuyBuy part
STAFF, SCREWLESS	723/1129		BuyBuy part
STEM	401/299 (use 200/1275F)	401/299	BuyBuy part
STEM, FEMALE	360/256 (use 360/264)	360/256	BuyBuy part
STEM, FEMALE OA10.25	360/314	360/314	BuyBuy part
STEM, FEMALE OA9.1 SH2.6	360/264	360/264	BuyBuy part
STEM, HUB 1.35 TAP 10 OVERSIZE	200/52F	401/AS 984	BuyBuy part
STEM, T10	200/1275F	401/AS 1506	BuyBuy part
SWEEP SECOND BEARING PLATE	342/38		BuyBuy part
THIRD WHEEL	210/747		BuyBuy part
THIRD WHEEL, C/S	217/39	/AS 1664	BuyBuy part
TWO ARM SPRING	M/1893	HACK/AS 1700	BuyBuy part
UNLOCKING YOKE	A/3622	2632/1/AS 1681	BuyBuy part
UNLOCKING YOKE SPRING	A/3623	2633/AS 1681	BuyBuy part
UNLOCKING YOKE SPRING	A/5607	2633/AS 1681	BuyBuy part
UPPER AUTOMATIC DEVICE BRIDGE	A/2390	1142/AS 1580	BuyBuy part
UPPER SHOCK UNIT 313X10	400/1712	110.21.313.10	BuyBuy part
UPPER UNIT D310 H10 INCA	400/841	100.21.310.10	BuyBuy part
WINDING PINION	410/725	410/AS 1580	BuyBuy part
