Henzi Pfaff 104
Ligne: 18.5'''
Jewels: 15
Power Reserve: 41 hrs
Frequency: 18000 vph
Type: Manual Wind
Diameter: 41.65 mm
Height: 5.3 mm
Hands: 2.00 x 1.15 / 0.27 mm
The Henzi Pfaff 104 watch movement is an open face calibre with optional Breguet hairspring. It features varying bridge shapes and may include a left-handed ratchet-wheel screw. The differences among calibres 231, 235, 239, 243, 249, 255, 259, 265, 271, 277, 447, 449, 471, 477, and 508 are not known, but are likely catalog designations for different bridge shapes. The movement functions include stem wind and set, as well as a sub-second feature.
The Henzi Pfaff 104 features the following functions:
- Stem wind and set
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.10 x 0.210 x 490 x 17.0 mm | Manual | Buy mainspring | |
| 2.10 x 0.210 x 480 x 16.0 mm | GR6106 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
