Henzi Pfaff 103
Ligne: 10.5'''
Jewels: 16/17
Lift Angle: 58°
Power Reserve: 40 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1950-
Diameter: 23.7 mm
Height: 4.7 mm
Hands: 1.40 x 0.84 x 0.25 mm
The Henzi Pfaff 103 watch movement is a manual wind movement with sweep second functionality. It is also available in variations with non-sweep seconds. Additionally, there is an automatic version of this movement. The Henzi Pfaff 103 movement was used in watches from the 1950s onwards.
The Henzi Pfaff 103 features the following functions:
- Automatic Winding
- Manual Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.100 x 320 x 9.5 mm | GR4123X | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
