Hamilton 88
Ligne: 6.75 x 11'''
Jewels: 15
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Size: 15.4 x 25 mm
Height: 4.0 mm
Hands: 1.20 x 0.65 / 0.18 mm
The Hamilton 88 is a manual wind mechanical watch movement with sub-second functionality. It belongs to a group of movements that includes the 765 through 769, 842, and 843, with no known differences among them. The Hamilton 88 movement was commonly used in watches produced around the 1940s.
The Hamilton 88 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.45 x 0.095 x 320 x 9.0 mm | GR3943 | Manual | Buy mainspring |
| 1.45 x 0.090 x 315 x 9.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
