Hamilton 694A
Ligne: 11.5'''
Jewels: 25
Power Reserve: 44 hrs
Frequency: 21600 vph
Type: Automatic
Period used: ~1970
Diameter: 26 mm
Height: 5.1 mm
Hands: 1.50 x 0.90 x 0.21 mm
The Hamilton 694A watch movement features a ball-bearing rotor and an excenter winding mechanism. This movement is equipped with various functions including automatic winding, sweep seconds, adjustable stud holder, and shock protection. It was manufactured and used during the approximate period of 1970.
The Hamilton 694A features the following functions:
- Adjustable Stud Holder
- Automatic Winding
- Ball-bearing Rotor
- Shock Protection
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.100 x 9.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
